Sunfire X24 - Page 21

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 21
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
60" SINGLE OR DOUBLE STANDARD OVENS / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION
OVEN LEFT OVEN RIGHT DOUBLE OVENS
FROM UP TO
CRITICAL
33B 4522646
Door Handle, Sunre, 1.0” Dia
Note: Used FROM (date) 15-Aug/08 (serial#)
0808100100641 (model) X60-10RR-0001.
1 1 2 15AUG/08
33C 4525581
Oven Door Handle Kit, 26W, Sunre
Note: Kit includes items 31B, 32B, 33B
1 1 2 15AUG/08
34A 1082802 Hinge Link R/H 1 1 2 C
34B 1082803 Hinge Link L/H 1 1 2 C
35 4522772 Bell Crank Assembly 2 2 4
36 F299 Bolt 1/4-20x1/2" Bell Crank 2 2 4
37 4522818 Bell Crank Support Bracket 2 2 4
38 4512250 Oven Door Spring 2 2 4 C
39 4523497 Oven Door J-Bolt, 6” (F598) 1 1 2
40 4526109 Door Spring Adjustment Bracket 1 1 2
41 4522770 Kick Panel 26W 1 1 2
42
4525442 Knob Assembly - Sunre Oven SIT, deg. F 1 1 2 C
4525443 Knob Assembly - Sunre Oven SIT, deg. C 1 1 2 C
43 4523081 ES Shield Mount 1 1 2
44 4523006 SIT Oven Control 1 1 2 C
45 1095499 Straight Connector 7/16 2 2 4
46 4523079 ES Shield Right 1 1 2
47 4523080 SIT Left Shield 1 1 2
48 4523499 SIT Top Shield 1 1 2
49 4523145 Tube - Sit To Manifold 1 1 2
49A 4520720
7/16" Flexible Tubing Sit To Manifold
Note: Applicable Only to Models with 12" Griddles
Mounted on the L/H Side of the Range.
  1
50 4522412 Rack Guide, R/H, 22D, Sunre 1 1 2
51 4522409 Oven Rack 26W x 22D 1 1 2
52 4522754 Rack Guide, L/H, 22D, Sunre 1 1 2
55A 4522990 Corner Column L/H   1
55B 4522993 Corner Column R/H   1
55C 4522991 Center Column   1
57 F298N
Bolt, #10-24 x 3/8" Shoulder Truss HD, Nickel Plated
(was F298)
2 2 4
58 4523255 60" Plate Rail, Sunre   1
59 4527427
Valve Panel End Cap - Left (was 4523251)
Note: Used from (serial#) 0911100100549 (model)
X60-6R24RR-0003.
  1 17NOV/09
60 4527426
Valve Panel End Cap - Right (was 4523250)
Note: Used from (serial#) 0911100100549 (model)
X60-6R24RR-0003.
  1 17NOV/09
61 4526110 Burner Box Filler (was 4523193)   2
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
