SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
60" SINGLE OR DOUBLE STANDARD OVENS / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION
OVEN LEFT OVEN RIGHT DOUBLE OVENS
FROM UP TO
CRITICAL
62
4523583
60” Valve Panel
All burners or 12” Griddle (Std) on L/H or R/H
Note: Used from (serial#) 0911100101162.
(4523581 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
4523977
60” Valve Panel - 24” Griddle (Std) on R/H
Note: Used from (serial#) 0911100101162.
(4523577 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
4523554
60” Valve Panel - 24” Griddle (Std) on L/H
Note: Used from (serial#) 0911100101162.
(4523573 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
4523474
60” Valve Panel - 36” Griddle (Std) on R/H
Note: Used from (serial#) 0911100101162.
(4523577 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
4523527
60” Valve Panel - 36” Griddle (Std) on L/H
Note: Used from (serial#) 0911100101162.
(4523659 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
4524354
60” Valve Panel - 48” Griddle (Std) on R/H
Note: Used from (serial#) 0911100101162.
(4524457 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
4524356
60” Valve Panel - 48” Griddle (Std) on L/H
Note: Used from (serial#) 0911100101162.
(4524458 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
4524360
60” Valve Panel - 60” Griddle (Std)
Note: Used from (serial#) 0911100101162.
(4524457 is obsolete, used up to 01-Dec/09)
  1 2DEC/09
62A 4523746 2.5” Valve Panel Hole Cover (Storage Base Option)
63 4522564 Manifold Assembly (without Fittings)   1 C
64
4522421 Regulator - Natural Gas 4.5" WC   1 C
4522422 Regulator - Propane Gas 10" WC   1 C
65 4529768
90 deg Elbow Fitting,7/16CC to 3/8NPT (was
G02352-1)
1 1 2
66 G022511 Pressure Test Spigot   1
67 2203400 1/8" NPT Pipe Plug 2 2 4
70 4522774 Air Shield Pilot 26W 1 1 2
71 4522773 Air Shield Solid 26W 1 1 2
72 4523031 Capillary Guard 26W Standard Oven 1 1 2
73 4523030 Bulb Guard Standard Oven 1 1 2
74 4523194 Rail Support Bracket   2
75 1082700 Harness Ring, Nickel Plated 2 2 4
76 4522400 Trunion Bracket 2 2 4
77 4523087 Grate Support Rail   3
78 4523069 Drip Angle, Large, 36”   2
79 4523186 Drip Angle, 24”   2
80 4530485
.437 (7/16) Dia Oven Tubing, SIT Valve to Oven
Orice, Oven on the Left
1  1
81 4530483
.437 (7/16) Dia Oven Tubing, SIT Valve to Oven
Orice, Oven on the Right
 1 1
82 4523570
.187 (3/16) Dia Tubing, SIT Valve to Oven Pilot,
Oven on the Left
1  1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
