U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 23
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
60" SINGLE OR DOUBLE STANDARD OVENS / CABINET DOOR COMPONENTS
ITEM PART# DESCRIPTION
OVEN LEFT
OVEN RIGHT
DOUBLE OVENS
FROM UP TO
CRITICAL
82A 4527220 SIT Pilot Tube Connection 1
83 4523686
.187 (3/16) Dia Tubing, SIT Valve to Oven Pilot,
Oven on the Right
1 1
85 4522996 Tie Strap Top 1
86 4522995 Tie Strap Front 1
89 4525043
Hearth Support, L/H 36” (removable)
Note: Used FROM (serial#) 0804100101527
(model) X60-10RR.
1 1 2 1MAY/08
90 4525044
Hearth Support, R/H 36” (removable)
Note: Used FROM (serial#) 0804100101527
(model) X60-10RR.
1 1 2 1MAY/08
91 4523032 Fireplate, 26W Oven, Sunre 1 1 2
92 4522385 Oven Hearth 26W x 22D - Enamelled 1 1 2
95 F16
SIT to Manifold Mounting Bolts (#10-24 x 2-1/2",
Round Head, Slot Drive)
2 2 4
96 F312
SIT to Manifold Mounting Lock Nut (#10-24, K-Lock
Nut)
2 2 4
LEGS & CASTERS
200 4522416 6" Adjustable Leg, Sunre 4
201 4524104 6" Flanged Leg (Optional) 4
202 4526324
6" Caster Package, non-adjustable (Optional)
Note: Includes items 204, 205, 208, and installation
instructions.
1
203 4526323
6" Caster Package, adjustable (Optional)
Note: Includes items 206, 207, 208, and installation
instructions.
1
204 4522417 6" Caster No Brake, 3/4-10 mount, non-adjustable 2
205 4522916 6" Caster With Brake, 3/4-10 mount, non-adjustable 2
206 4525597 6" Caster No Brake, 3/4-10 mount, adjustable 2
207 4525598 6" Caster With Brake, 3/4-10 mount, adjustable 2
208 4526157
Caster Washer
Note: Used FROM (serial#) 0901100100838 (date)
20-Jan-09.
4 20JAN/09
209 4526325 Caster Washer Kit 1
DOOR COMPONENTS  STORAGE BASE MODEL
300 4524282 Door Panel Outer - 36", Standard Base 1 1
301 4524283 Door Panel Inner - 36", Standard Base 1 1
302 F557 5/32" Rivet - S/S (Grip Range .039" - .118")
10 10
303 0780565 Flange Bearing/Bushing 2 2
304 2530900 0.375" Hole Plug 2 2
305 3031900 Storage Door Handle 1 1
306 4524288 Door Hinge Assembly - Right 1 1
307 4524287 Door Hinge Assembly - Left 1 1
308 4524284 Door Stop - 36" Door, Standard Base 1 1
309 F60 Screw-10AX 5/8 InterLock Quad Pan 8 8
310 0781741 Magnetic Door Catch 1 1
311* 4523669 Logo, Stick-On, Sunre 1 1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
