SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
HI / LOW GRIDDLE TOP
ITEM PART# DESCRIPTION
GRIDDLE SIZE
FROM UP TO
CRITICAL
12" 24" 36" RIGHT 36" LEFT 48" RIGHT 48" LEFT 60"
1 4525514
Hot Top / Griddle Burner Box (was
4523179)
1 2 3 3 4 4 5
2 4524158 Griddle / Hot Box Patch 1 2 2 2 2 3
3A 4524326 12" Chute Rear Plate 1
3B 4524325 12" Grease Chute Funnel 1
4A 4523219 Grease Chute Rear Plate 1 1 1 2 2 2
4B 4523218 Grease Chute Funnel 1 1 1 2 2 2
5 4523217 Grease Drawer Handle 1 1 1 2 2 2
6 4523221 Grease Drawer Shield 1 1 1 2 2 2
7 4523493 Grease Drawer Assembly 1 1 1 2 2 2
9 1028002 Air Shutter - Hot Top / Griddle 1 2 3 3 4 4 5
10 4525463
H-Burner w/ Shutter Assembly (Partially
Ported)
Note: Assembly includes a cast iron
H-burner (p/n 1014901) and an air shutter.
1 2 3 3 4 4 5
12
4524416
6” False Trim S/S
(For any 60" unit w/ a 48" Griddle Left)
1
4523552 16” False Trim S/S 1 1 1
4523690
17” False Trim S/S
(For any 36" unit w/ a 24" Griddle Right)
1
4523528
28” False Trim S/S
(For any 60” Griddle; 36" unit w/ a 36"
Griddle; any 60" unit w/ a 36 Griddle Left )
1 1 1
4523516
29” False Trim (For any 60" units w/ a 36"
Griddles Right)
1
13 4523519 False Trim Bracket 2 2 2 4 6 4
14 4525515 Burner Side Deector 2 4 6 6 8 8 10
15
4523418 Rear Griddle Splash Guard - 12" 1
4523419 Rear Griddle Splash Guard - 24" 1
4523420 Rear Griddle Splash Guard - 36" 1 1
4523421 Rear Griddle Splash Guard - 48" 1 1
4523422 Rear Griddle Splash Guard - 60" 1
17 4525503 Sit Pilot Bracket (was 4523176) 1 2 3 3 4 4 5
18 2200701 Pilot L/H #0.145.007 1 2 3 3 4 4 5 C
19
2200702 Pilot Orice #32 (Natural Gas) 1 2 3 3 4 4 5 C
2200703 Pilot Orice #23 (Propane Gas) 1 2 3 3 4 4 5 C
20 2200705 3/16" Ferrule - Pilot 1 2 3 3 4 4 5 C
21 2200704 3/16" Compression Nut - Pilot 1 2 3 3 4 4 5 C
22 1086597 Pilot Gum Valve 1 2 3 3 4 4 5
23 4523286 3/16 Tubing Pilot to Gum Valve 1 2 3 3 4 4 5
24 4523483 Hot Top Valve Ext. Support 1 2 3 3 4 4 5 1DEC/09
26
1086580
Hi-Low Valve Assembly Natural Gas #47
w/Extension & Orice
1 2 3 3 4 4 5 1DEC/09 C
1086595
Hi-Low Valve Assembly Propane Gas
#1.3mm w/ Extension & Orice
1 2 3 3 4 4 5 1DEC/09 C
27 4522401 Crumb Tray 1
28 4522403 Crumb Tray Trim 1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
