Sunfire X24 - Page 30

U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10)Page 30
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
HI / LOW GRIDDLE TOP
ITEM PART# DESCRIPTION
GRIDDLE SIZE
FROM UP TO
CRITICAL
12" 24" 36" RIGHT 36" LEFT 48" RIGHT 48" LEFT 60"
29 CK4523335 Crumb Tray Assembly, Sunre 1
30 F554 Rivet .125" Dia. SS 1
31 4525512 Griddle Box Heat Shield 1 2 3 3 4 4 5
33 4525452 Knob Assembly, Hi-Lo Griddle, X Series 1 2 3 3 4 4 5 C
35A
M847 Hot Top/Griddle Orice Natural Gas #47 1 2 3 3 4 4 5 C
M81.3MM
Hot Top/Griddle Orice Propane Gas
#1.3mm
1 2 3 3 4 4 5 C
35B G02486XX
Orice Fitting (without orice)
Note: Used FROM (serial#)
0911100101162 (model) G60-
6G24RR-0002
1 2 3 3 4 4 5
2DEC,
2009
C
35C*
G02486
47F
Orice Fitting 47F - Natural Gas 1 2 3 3 4 4 5 C
G02486
1300
Orice Fitting 1.3mm - Propane Gas 1 2 3 3 4 4 5 C
36 4527389
Orice Bracket
Note: Used FROM (serial#)
0911100101162 (model) G60-
6G24RR-0002
1 2 3 3 4 4 5
2DEC,
2009
38
Note: Production switched from 12" ex tubing to 6" as of 22-JAN-2010. The 6" version is
sucient.
4521446
1/4" Flex Tubing, 12" Long (Valve to
Orice Fitting) Note: Used FROM
serial#: 0911100101162 / model: G60-
6G24RR-0002
1 2 3 3 4 4 5
2DEC,
2009
21JAN,
2010
4525331
1/4" Flex Tubing, 6" Long, S/S (Valve to
Orice Fitting)
1 2 3 3 4 4 5
22JAN,
2010
39A
4524442 1/8 NPT Hex Piple Nipple 1 2 3 3 4 4 5 2DEC/09
28FEB,
2010
4527682 Coupling 1/8 NPT Brass 1 2 3 3 4 4 5 2DEC/09
28FEB,
2010
39B 4527831
Extension 1/8" NPTMale To NPTFemale
Brass
Note: Replaced both items in 39A.
1 2 3 3 4 4 5
1MAR,
2010
C
40 G0259901
HI-LOW Valve with 90 Degree Elbow
Note: Used FROM (serial#)
0911100101162 (model) G60-
6G24RR-0002.
1 2 3 3 4 4 5 2DEC/09 C
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
