U_GMD_PL_RANGESXSERIES_XSERIES (Rev 10) Page 31
SUNFIRE PARTS IDENTIFICATION
X Series Gas Restaurant Ranges models X24, X36, X60
HI / LOW GRIDDLE TOP
ITEM PART# DESCRIPTION
GRIDDLE SIZE
FROM UP TO
CRITICAL
12"
24"
36" RIGHT
36" LEFT
48" RIGHT
48" LEFT
60"
48
4523235 12" Griddle Assembly 1
4523780 12" Griddle Assembly (Fully Grooved) 1
4523234 24" Griddle Assembly 1
4523781 24" Griddle Assembly (Fully Grooved) 1
4523782 24" Griddle Assembly (Right Grooved) 1
4523783 24" Griddle Assembly (Left Grooved) 1
4523236 36" Griddle Assembly 1 1
4523784 36" Griddle Assembly (Fully Grooved) 1 1
4523785 36" Griddle Assembly (Right Grooved) 1 1
4523786 36" Griddle Assembly (Left Grooved) 1 1
4523387 48" Griddle Assembly - R/H Side 1
4523787
48" Griddle Assembly (Fully Grooved) -
R/H Side (on any 60” unit)
1
4523788
48" Griddle Assembly (Right Grooved) -
R/H Side (on any 60” unit)
1
4523789
48" Griddle Assembly (Left Grooved) - R/H
Side (on any 60” unit)
1
4524404
48" Griddle Assembly - L/H Side
(on any 60” unit)
1
4523388 60" Griddle Assembly 1
* NOT ILLUSTRATED
