• Power Cut: If you haven’t configured software on the Raspberry Pi, or for other reasons, you can opt for a power
cut shutdown. Press and hold the button for 5 seconds and turns red, indicating a direct power cut. Be cautious
with this method as it may damage data.
RGB
The RGB is a common-cathode RGB. Once the RGB button is connected, the RGB light will display the current status,
which includes:
RGB Status
Green Light External Power Input Status
Yellow Light Battery Power Status
Orange Light Cycling from Dim to Bright Charging
Red Light Flashing Low Battery (and not charging)
Purple Long Press 2 Seconds, Soft Shutdown
Red Long Press 5 Seconds, Hardware Shutdown
Off Sleep/Not Powered
Wiring
The button interface is MX1.25 5P. Use the MX1.25 5P reverse cable to connect the button to the Pironman U1 HAT.
The button pin definitions are:
K Button Signal
B Blue Positive Signal
G Green Positive Signal
R Red Positive Signal
C GND
6.6. Power Button 59
