1 2
1
.
Brie
f
Int roduction. . ...... ...... ........... ..............................
2
2
.
Te c h n i c a
l
D a t a . . . . . . . . . . . . . . . . . . . . . . . . . .
.
. . . . . . . . . . . . . . . . . . . . . .
2
3
.
Function
s
an
d
Fea tures.................. ... . .............. . .......
2
4. Mechanism
Structure...........................................................4
5 .
Installatio
n
Directio
n
Definition................... .................
4
6. Mechanical Part Installation and
Adjustment.........................5
6.1. Cabinet
Installation........................................................5
6.2. Spring Selection, Installation and Adjustment...................5
7. Controller Explanations and Instructions ............................... 6
7.1. Controller Interface
Explanations....................................
7
7.2. Controller Auto-Detect after Power-On Description........... 8
8. Boom Horizontal and Vertical Fine Adjustment...................... 9
9. Working Codes Meanings and Error Code Solutions...... ...... .. 9
10. Warranty and Service
Items..................................................11
11.
Maintenance.....................................................................11
12. Packing
List......................................................................11
I. Tabl e of Spr i ng Sel e c ti o n an d Sugg e ste d Ma x Sp e ed wit h
B o o m L e n g t h
. . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 11
II
. Appendix II : Remote Control Coding
.......................................12
I I I
. Wiring
Diagram
for R&G Light Interface
.............................1 3
IV. W i r i n g D i a g r a m f o r u p a n d d o w n l i m i t o u t p u t . . . 1 3
V. System Menu Setting Procedures
...............................................11
VI
. Setting Menu Explanations
.....................................................12
VI I
. Digitron Display Code and Meanings
.............. . .... .. ... . ... . 1 3
For safety, please do follow the instruction strictly to operate
1. Make sure there is no person or any obstruction under the boom
when it is power on, resume or falling.
2. There must be a grounding connection for the barrier
3. It is forbidden to open the barrier cabinet top cover or door when
4. Before delivery, the barrier gate spring and the boom length are
well-balanced. It is not allowed to change the boom length
randomly. If needed, please check with the technician.
SUNFRE S10 DC Brushless Servo motorized barrier gate, the
newly designed, maintenance free with exclusive SFMCU
MicroDrive unit offers 100% more torque, 100% duty, are the
fastest toll barriers available with an opening time as fast as 0.6
seconds. Opening speed is adjustable from 0.6s/0.9s to 6s or
This barrier redefines performance in non-stop toll applications.
It is the ideal solution for very high frequented toll stations
providing great reliability and sustainability as well as
comprehensive functionality.
This Barrier use innovative technology design and manufactured
with precision machinery to guarantee satisfaction in quality and
reliability for years to come. The barrier has been lab tested for
more than 10 millions opening /closing and still without any
2. Technical Data
2.1 Working temperature (motor): -35°C~ + 85°C
2.2 Working Power: 220V±10%, 110V ±10%
2.3 Motor Rated Power: 100/200W MAX
2.5 Distance of remote control: L≥30M
3. Functions and Features
3.1 NO SENSOR&LIMIT SWITCH
Innovative design which doesn’t need any sensor and limit switch.
All control by SFMCU drive unit precisely. Four main parts only,
mechanical, motor, control unit, power supply.
DC Brushless Servo motor doesn’t need a carbon brush while brush
motor request you replace the carbon brush in a certain time.
Galvanized and powder coated parts are anti-rust ensure long term
usage. And no other smaller parts need to be maintain too.
3.3 24/7 CONTINUS OPERATION
With a very smooth and quiet motorized drive mechanism, Open
and close very stable, offer maximum reliability at fast speeds,
