2.2 Appearance and Structure
The product appearance is shown in the following pictures.
No. Name
A Door lock*
B Air inlet
C
Top ring
*The door lock position is for reference only, please refer to the actual product.
2.3 Overall Dimensions
The external dimensions of the product are shown below.
Width
Height Depth Weight
800±10mm 2260±15mm 600±10mm
246±5kg
