Sungrow SG12RT - Installing the AC Connector (≥ 15 Kw)

43
Observe the terminal assignment. Do not connect any phase line to the "PE" termi-
nal or PE wire to "N" terminal. Otherwise, unrecoverable damage to the inverter
may follow.
step 8 Ensure that the wires are securely in place by slightly pulling them. Tighten the swivel nut to
the housing.
- - End
5.5.5 Installing the AC Connector (≥ 15 kW)
High voltage may be present in inverter!
Ensure all cables are voltage-free before electrical connection.
Do not connect the AC circuit breaker until all inverter electrical connections are
completed.
step 1 Disconnect the AC circuit breaker and secure it against reconnection.
step 2 Remove the waterproof lid from the AC terminal.
User Manual 5 Electrical Connection
