124
Parameters SH12T SH15T
Surge Protection DC Type II / AC Type II ***
PID Zero Yes
Parallel operation on grid port Master-slave mode
Battery input reverse polarity
protection
Yes
General Data
Topology (solar / battery) Transformerless / Transformerless
Degree of protection IP65
Dimensions (W x H x D) 620 * 480 * 195 mm 620 * 480 * 245 mm
Weight 32kg 38kg
Mounting method Wall-mounting bracket
Operating ambient tempera-
ture range
-25 ℃ - 60 ℃
Allowable relative humidity
range(Non-condensing)
0% - 100%
Cooling method Natural convection
Max. operating altitude 2000m
Noise（Typical） 35dB(A)
Display LED
Communication
RS485, WLAN, Ethernet, CAN
DI / DO DI * 4 / DO * 2 / DRM0
DC connection type
MC4 ( PV, Max.6mm² ) / Plug and play connector ( bat-
tery, Max.10mm² )
AC connection type Plug and play connector ( Max.16mm² )
Country of manufacture China
* Depending on the connected battery.
** Can be reached only if PV and battery power is sufficient.
*** Only when the DC switch is set to "ON", the DC Type II is able to provide effective protec-
tion against electrical surges.
Note:The output voltage of strings should all exceed the lower limit of the full load MPPT
voltage range. The difference in string voltage between different MPPTs should be less than
150V.
Parameters SH20T SH25T
Input (DC)
Recommended max. PV in-
put power
40000 Wp 50000 Wp
Max. PV input voltage
1000 V
11 Appendix User Manual
