42
RS-232 ExpressCard Interface
Port Connecter Baud Rate ESD Protection Bracket Model NO.
4 34mm ECS4000
2
DB44 Female
34mm ECS2000
1 DB9 Male
921.6Kbps
±15KV
34mm ECS1000
RS-232 CardBus Interface
Port Connecter Baud Rate ESD Protection Bracket Model NO.
4 54mm CBS4000
2
DB44 Female
54mm CBS2000
1 DB9 Male
115.2Kbps
±15KV
54mm CBS1000
RS-232 PCI/104 Interface
Port Connecter Baud Rate ESD Protection Model NO.
8 SER5337A
4 SER5356A
2
5x2 Pin Header 115.2Kbps
±2KV
SER5366A
