Sunix RS-422 - Product Specifications

___________________________________________________________________________________
7
Product Specifications
Serial Communication
Driver Support
Regulatory Approvals
Environment
Interface RS-422/485 Baud rate 50bps ~921.6Kpbs
Controller
SUNIX SUN1999
(16C950 UART Compatible)
Stop bit 1, 1.5, 2
BUS
Universal PCI 64/32bit
PCI Spec.Ver3.0/2.3/2.2/2.1
Parity even, odd, none, mark, space
No. of Port 1/2/4/8/16-port
Flow
Control
None, Xon/Xoff, RTS/CTS
IRQ & IO Assigned by System FIFO 128byte Hardware
Signal
RS-422: TxD+, TxD-, RxD+, RxD-, GND
4-wire RS-485: TxD+, TxD-, RxD+, RxD-, GND
2-wire RS-485: Data+, Data-, GND
ESD
Protection
±15KV ESD protection for each signal Human Body Model (HBM)
±15KV IEC1000-4-2 Air Gap Discharge
±8KV IEC1000-4-2 Contact Discharge
Surge
Protection
500W peak surge protection for all signal lines meet IEC 61000-4-5
(SI Version Only)
Isolation
Protection
2.5 KV Isolation Protection for all signal and power
(SI Version Only)
Connector DB9 / 25 Male
Microsoft Client
XP / Vista / 7 (X86/X64)
Microsoft Server
2000 / 2003 / 2008 (X86/X64)
Microsoft Embedded XP Embedded / POS Ready 2009 / Embedded System 2009
Linux Linux 2.4.x / 2.6.x
DOS DOS
Hardware
EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3,
FCC Part 15 Class B, RoHS
Software
Microsoft WHQL Windows
Microsoft Client: XP / Vista / 7 (X86/X64)
Microsoft Server: 2000 / 2003 / 2008 (X86/X64)
Operation Temperature 0 to 60°C (32 to 140°F)
Operation Humidity 5 to 95% RH
Storage Temperature -20 to 85°C (-4 to 185°F)
