Know Your Electric Pressure Washer + Wet/Dry Vacuum
Read the owner’s manual and safety rules carefully before operating the pressure washer + wet/dry vacuum. Compare the
illustration below to the unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.
6
Technical Data
Rated Voltage 120 V ~ 60 Hz
Motor 12 A (Pressure washer)
10 A (Vacuum system)
Max. Water Inlet Temperature 104ºF/40ºC
Max. Water Inlet Pressure 0.7 MPa
Max. Flow 1.45 GPM
Detergent Tank Capacity 27 oz (0.8 l)
Rated Pressure 1133 PSI
Max. Pressure 1700 PSI
High-pressure Hose Length 20 ft (6.1 m)
Power Cord Length 35 ft (10.7 m)
Air Flow 1.5 m
3
/min
Dust Tank Capacity 0.8 gal (3 l)
Working Air Pressure ≥12 Kpa
Weight 28.4 lbs (12.9 kg)
1. Handle
2. Trigger gun
3. Trigger gun holder
4. Dust tank
5. Water outlet
6. Air outlet
7. Wheel (2)
8. Air inlet ( Vacuum hose connector)
2
3
4
5
6
7
10
8
11
12
13
14
15
16
17
9
1
9. Power cord restraint hook
10. High pressure hose
11. Vacuum hose
12. High-pressure hose hanger
13. Trigger
14. High pressure hose connector
15. Water inlet (garden hose connection)
16. Power cord with GFCI
17. Detergent bottle
18. Extension tubes (2)
19. Spray wand
20. Adjustable nozzle
21. Dusting brush
22. Crevice nozzle
23. Furniture brush
24. Wet/dry bristle brush
25. Wet/dry oor brush
18
19
20
22
23
24
25
21
