- 14 -
NOTE:
Here only for signal control never drive
it directly.
Power In
380V/50Hz/3phases
Figure 13 Power cable terminal
7.2 Electrical Wiring Specification
Model No.
Electrical Wiring Specification
YC-050TA1
3*6mm²+2*4mm²
7.3 Circulation pump installation
The heat pump only provide the signal for circulation pump, must use an a.c. Contactor to
connect the circulation pump.
Figure 14
