Rev 10-21-05 SunSetter Products, a Massachusetts Limited Partnership, 184 Charles St, Malden MA, 02148
Page 2 of 2
6. Insert the new drive unit into the roller bar. Secure by installing the supplied Phillips screws into the
three holes on the end of the roller bar.
7. Using a Phillips screwdriver, remove the crank loop from the old drive unit and install on the new drive
unit.
8. On the right end, orient the drive unit so that the crank loop is pointing towards the HOUSE. Assemble
the ends of the rafter and arm to the roller and secure with the flat-head cap bolt. Tighten with a 7/32”
Allen wrench.
9. Check the opposite side of the roller: IF THE LEFT ROLLER INSERT IS SECURED TO THE
ROLLER WITH 3 DRIVE RIVETS, YOU MUST FOLLOW STEP 10 AND REPLACE THE RIVETS WITH
THE 3 PHILLIPS SCREWS AND PLASTIC ANCHORS SUPPLIED! If the left roller insert is secured to
the roller with 3 Phillips screws, go to step 11.
WARNING: FAILURE TO REPLACE THE 3 DRIVE RIVETS ON THE LEFT SIDE OF THE ROLLER
CAN RESULT IN PERSONAL INJURY!
10. Replacing the Drive rivets on the left side of the roller
A- Make sure that the fabric is completely extended. Do not lock the rafters. Place a chair or box under
the roller bar for support.
B- On the left side of the roller, using a small nail or punch, drive the centers of the three rivets all the
way thru into the roller. Pry the rivets out of the holes with a flat screwdriver.
C- Pull the left roller insert out of the roller bar. Remove the rivet centers from inside the roller bar or they
will rattle when you operate the awning.
D- On the roller insert, locate the three holes close to the end and snap the 3 plastic screw anchors
supplied into the holes from the outside.
CAUTION: Be sure that the screw anchors are pressed firmly into the holes.
E- Insert the roller insert back into the roller bar. Secure by installing the supplied Phillips screws into the
three holes on the end of the roller bar.
11. Test the awning for proper operation.
