For Technical support visit us at hp://ownerscorner.sunseer.com
e-mail at contactus@sunseer.com or call Toll Free 800-670-7071 • Fax 877-224-4944
OWNER’S MANUAL
& INSTALLATION
INSTRUCTIONS
Do Not Discard,
Retain for Future Reference
Manual
Awnings
and
Motorized Awnings
WARNING:
FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD
RESULT IN
PERSONAL INJURY!
Awnings by SunSeer
Featuring Sunbrella Fabrics

Table of Contents

Questions and Answers

  • K
    karenmillerAug 7, 2025
    What to do if SunSetter Accessories awning/motor doesn't respond to the remote properly?
    • G
      Glenn OrtegaAug 7, 2025
      First, unplug the motor, wait two seconds, and plug it back in. If the motor jogs, proceed to Section A. If it doesn't, go to Section B. Section A involves pressing and holding the CLOSE and OPEN buttons together on the remote until the motor jogs, then pressing and holding the PROGRAMMING button until the motor jogs again. Finally, test for proper operation. Section B involves pressing and holding the CLOSE and OPEN buttons together on the remote until the motor jogs, then performing Steps 9-18 in Appendix D on Page 26. Finally, test for proper operation. If neither Section A nor Section B fixes the issue, perform Steps 1-18 in Appendix D on Page 26, or call SunSetter Technical Support at 800-670-7071.
  • J
    Jennifer ParkAug 21, 2025
    How to self test the SunSetter Accessories remote transmitter?
    • S
      Shawna NorrisAug 21, 2025
      To self-test the remote transmitter, press each button (CLOSE, OPEN, my) on the front of the remote, one at a time. Hold each button for 5 to 10 seconds. The LED light should blink for at least 5 seconds, then stop blinking. If this happens, the remote transmitter is working correctly. If not, replace the remote transmitter’s battery with a new Lithium CR2430.
