60
A. Insert USB flash drive containing the pattern to
change the 2nd original point.
B. Press MODE key.
C. After moving to “2. Program” menu by using
direction key , press ENTER Key. At this
time, the upper feed plate comes down and
moves to the original point.
ORIGIN
X:00000A N:00000
Y:00000A
Function Code?
3-7) Change/Saving Function of Pattern 2nd Original Point
Change the already setup 2nd original point to new 2nd original point and save it.
New 2nd Original Point
2nd Original Point
Sewing Start Point
Movement
Original Point
014:PTRN READ
NO :001
D. After pressing READ key, input the pattern
number to change the 2nd original point by
using digit key and read in the pattern by
pressing ENTER key. (For example, input
[0][0][1] to read the pattern number 001.)
SEC_ORG NONE
X:-0260A N:00025
Y:00120A
Function Code?
E. Go to the location of 2nd original point by
using FORW and BACK key.
To Next Page
