SunStar SPS/A-Pattern Series - Page 61

61
<Function Code>
054:MOV 2ndORG<
055:AUTO TRIM
056:SCALE REFER
F. After pressing CODE key, if you know the
function number related to pattern programming,
input three-figure digit number 054 and if you
do not know the number, press ENTER key.
Then, after moving to “054:MOV 2nd ORG”
by using direction key , press ENTER key.
※ X-Y position value may differ according to
the 2nd original point.
054:MOV 2ndORG
X:-0260
Y:00120
N:000
054:MOV 2ndORG
X:-0260
Y:-0050
N:000
G. Move to new 2nd original point by using direction
key.
JUMP
X:-0260A N:00023
Y:-0050A
Function Code?
H. Complete input of new 2nd original point by
pressing EXE key.
I. Confirm if change was made properly by using
FORW and BACK key.
015:PTRN WRITE
NO :008
J. Save the pattern of the changed 2nd original
point by pressing WRITE key.
3-8) Change/Saving Function of Maximum Pattern Sewing Speed and Extension/
Reduction Rate
Set up maximum sewing speed and extension/reduction rate by pattern.
A. Insert floppy diskette containing the pattern to
change maximum sewing speed and extension/
reduction rate.
B. Press MODE key.
