<Function Code>
063:SET TR3 <
H. Press key to program
The concerned function code is 063. If you want
to search it from the function code list, press
and move to with
direction keys .
063 SET TR3
ENTER
Release 3)
TR3(ThreadCODE
D. Pressing key will move feed plate according
to the computed data after computing pattern
data.
EXE
C. Press key and move to the original position
of the square by pressing keys .
And then press key.
PNT.SET
direction
JUMP
004:JUMP
X:-0650
Y:00300
N:001
JUMP NONE
X:-0650A N:00065
Y:00300A
Function Code?
E. Press key, input stitch width by pressing
number keys and then press key.
(Ex. Press to set stitch width at 3mm.)
[0][3][0]
ENTER
LINE
007:LINE
WIDTH:030[0.1mm]
F. Move to the first point position of LINE by
pressing keys .
Press key.
PNT.SET
direction
007:LINE
X:00650
Y:00300
N:001
G. Register the first point position of square by
pressing key. After computing pattern data,
feed plate will move according to the computed
data.
EXE
LINE NONE
X:00650A N:00104
Y:00300A
Function Code?
<< Main Menu >>
2. Program
3. Bobbin Wind
4. Machine Test
A. Press key.
MODE
ORIGIN
X:00000A N:00000
Y:00000A
Function Code?
B. Move to “2. Program”by pressing keys
and press key.
Upper feed plate will come down and move to
original point.
ENTER
direction
