ELECTRONIC STABILITY CONTROL (ESC)
This is the most significant advancement in mobility scooter safety
ever designed and has dramatically reduced accidents due to
operator misuse. Turning corners at excessive speed has always
been one of the most common causes of accidents but with clever
engineering and sophisticated electronics we have all but eliminated
this problem. The speed of the SupaScoota is now electronically
governed in direct proportion to the rotation of the handle bars,
virtually eliminating any possibility of over speeding when turning.
With the handle bars at maximum rotation and the throttle at
maximum speed the scooter will turn at a very low speed with
complete safety. No other scooter can provide this level of safety.
Some situations may require maximum power to be used when
turning and we have allowed for this with a handlebar mounted push
button which will disable the ESC for 20 seconds if needed. (Push
button for one second)
Keep fingers and clothing
away from the Electronic
Stability Control sensor.
This vital piece of equipment
is very sensitive and could be
damaged, or could cause
damage, if tampered with.
Warning.
If the ESC is disconnected
or faulty, the scooter will continue
to function normally but the speed
will not reduce when turning.
- 23 -
SWIVEL SEAT (OPTIONAL)
When removing the seat, do not lift the release handle as this could
cause the seat support frame to disconnect from the seat and fall.
To turn the seat, lift and hold
the release handle below the
seat (as shown). This will
allow the seat to turn.
SPARE BATTERY TRAY (OPTIONAL)
- 24 -
