Specifications
Front Wheel Size 200mm (8”)
Rear Wheel Size Spartan: 200mm (8”)
Ground Clearance(tiller)
65mm (2.6”)
Length Spartan-1110mm (43.7”)
Width Spartan: 630mm (24.8”)
Front Frame Weight
Front Frame :13.5 kg (29.7 lbs)
Front Frame Without Front Wheel:11.3 kg (25 lbs)
Rear Frame Weight
Spartan-12.2 kg(27 lbs)
Weight of Seat 10.6 kgs(23.3 lbs included seat frame & armrest)
Max Loading
200 kg (440 lbs) on level ground (Included spare
battery & luggage)
Turn Radius 1000mm (39.4”)
Motor Output 2 x 180 Watt
Transmission Worm Drive Gearbox
Reverse Forward / Reverse Switch
Brakes Dynamic Braking and Electromagnetic Brake
Braking Distance / time 1-1.5 meter (39-59”) / 0.6 - 0.7 second
Battery (SLA / Lithium)
SLA: 24V - 15 ah 9.2kg (20 lbs) Lithium:
24V 12ah or 15ah / 3.2 kg (7 lbs) or 3.7 kg (8.1 lbs)
Charger (SLA/Lithium)
24 volt 2 amp / 24V 2 amp
Max Speed SLA Battery
Spartan: 6.2 kph (3.9 mph), 2
nd
speed 4.kph (2.5 mph)
Max Speed (UK)
3.9 mph
Slope Grade Ability
150 KG - 8 degree, 175 KG - 6 Degrees (max).
Travel Distance
Up to 9 km (5.6 miles) with standard SLA battery, / Up
to 12 Km (7.5 miles) or 9 km (5.6mile) with 24V 15ah
or 12ah lithium battery.
Arm Rests
Distance between armrests 45cm - 57cm (18 -22.4")
- 37 -
SPARTAN Warranty
Your SupaScoota is fully guaranteed against faults arising due to
defects in manufacture or materials as follows
Frame: 2 years.
The height adjustable tiller and all other components except those
listed below: 1 year.
Subject to availability of parts, any such defects will be rectified,
either by repair or by unit replacement.
Warranty does not cover
Any damage due to improper use nor the replacement of parts
arising from normal wear and tear such as potentiometers, tyres,
arm rests and upholstery.
Claims due to a normal increase in operational noise level.
This warranty does not cover labour or service calls.
Batteries
Batteries are covered by a six month warranty from the original
manufacturer. Gradual deterioration due to being left in a
discharged state or being left in cold conditions for long periods is
not covered.
This section MUST BE READ and SIGNED by the purchaser and
stamped by the dealer
This warranty record must be kept by the purchaser and a copy
supplied with any claim
-38-
