31
4 - Operation
AL. 4
éOFF
A4.Ou
éOP4
Ltch
éno
bloc
éno
bloc
éno
Ltch
éno
A3.Ou
éOP3
AL. 3
éOFF
bloc
éno
Ltch
éno
A2.Ou
éOP2
AL. 2
éOFF
donb
éno
donb
éno
donb
éno
-
AL2 alarm type
see table 11
AL2 addressing
OP1 / OP2 [1]
OP3 / OP4
AL21 latching
no / yeS
AL2 start-up
disabling
no / yeS
Disables AL2 if a sen-
sor break occurs
no / yeS
AL3 alarm type
see table 11
AL3 addressing
OP1 / OP2 [1]
OP3 / OP4
AL3 latching
no / yeS
AL3 start-up
disabling
no / yeS
Disables AL3 if a sen-
sor break occurs
no / yeS
AL4 alarm type
see table 11
AL4 addressing
OP1 / OP2 [1]
OP3 / OP4
AL4 latching
no / yeS
AL4 start-up
disabling
no / yeS
Disables AL4 if a sen-
sor break occurs
no / yeS
NOT AVAILABLE
OF
AL. 3 = OFF
NOT AVAILABLE
OF
AL. 2 = OFF
NOT AVAILABLE
OF
AL. 4 = OFF
Band
éAl 4
Description
Tab. 11 Alarm type
éAl 1
Value
Off
Not used or used by the
program (AL3/AL4)
fs.H
Active High
Absolute
fs.l
Active Low
deU.H
Active High
Deviation
deU.l
Active Low
bno
Active Out
bni
Active In
lba
Loop break alarm
(AL1 only)
éAl 3
éAl 2
tiMe
Alarm 3 active when
Timer ON
