When clamping, make sure that wire ropes
and other objects do not get caught between
Main body and Shackle.
⑦
Use as a suspending jig
is prohibited.
⑨
SCC0.5 and SCC-W (wide type) are for vertical lifting only.
They cannot be used for horizontal lifting.
(SCC0.5 can be used for horizontal lifting by using the long shackle
for SCC0.5 (SCH0.5L, sold separately).)
⑧
The clamps cannot be used on the following shaped structures.
⑥
Even in the case the wedge
shapes under 8°, lifting up in
tapering down direction is
prohibited.
Objects with uneven surface
(no flat surfaces) at grips.
Cylinders with inner
dia under 600mm
Curve shapes with
radius under 300mm
Round bars
※Wedge shapes over 8°
Prohibited
15
⑤
Clamps can also be used for positioning
steel structure for welding, pulling and/or
suspending.
