SuperFlow SF-1020I - Optional Air Filter Maintenance

40
6.4.5 Optional Air Filter Maintenance
Check Air Filter Assembly
The optional SF-1020i lter assembly is designed to capture airborne contaminants that are part of the
airstream during testing prior to entering the bench. These contaminants can be a nuisance as well as a
hazard. Use this maintenance procedure to perform a simple pressure test to determine the level of lter
clogging which relates to reducing the performance of the bench.
To measure the capacity of the bench and lter assembly:
1. Install only the standard test orice plate onto
the top of the SuperFlow owbench.
• Remove all of the rubber stoppers from the
test plate.
• Ensure that the test plate is sealed against
the base plate with the calibration sticker
visible.
2. Turn ON local system control or monitoring system. Do not turn the owbench motor ON at this time.
3. Set the owbench to Intake mode.
4. Set to Flow Range 10.
5. Set Test Pressure to 70.000 inH
2
0.
6. Set the local system to display or monitor Test Pressure.
7. Turn the owbench motors ON and monitor the test pressure. When the lters are new, the test
pressure should exceed 45 inH
2
0. This test pressure will vary based on air density, voltage supplied
to the bench, and the condition of the lters and motors. Record the maximum test pressure reached
when the bench and lters are new. The maximum test pressure will decrease as the motors heat
up, so it is best to perform this test before the
bench is used for any other testing. It is normal
to see some variation in this maximum pressure
reading from day to day because of air pressure
changes and motor temperature and power
variations, but this should not a󰀨ect the reading
more than 1.5 inH
2
0.
8. Over time, the maximum test pressure reached
will decrease as the lter media becomes
saturated with particulate.
This maintenance procedure does not address the
issue of potential re or health hazards associated
with captured contaminants. It is the responsibility
of the user/operator to develop a customized
procedure to address these hazards.
!
CAUTION
SuperFlow recommends servicing the lters when
the owbench is no longer able to reach 90% of the
test pressure that was possible when the lters were
new. Keep in mind that since other variables such
as power supply, motor condition, and atmospheric
pressure also a󰀨ect this reading, it is best to test the
lters on a regular basis and service the lters after
the 90% reading is consistently established. When the
performance of the bench drops below this 90% value,
clean or replace the lters.
NOTICE
6.0 Maintenance
