superior pump 92900 - Parts List

10
17
10
11
Qty - 5
14
Ref Description
PARTS FOR MODEL#
92900
92910
1 Power Cord 99158 99158
2 Handle 99051 99051
3 Oil Fill Plug with O-ring 99056 99056
4 Shaft Seal 99057 99057
5 Impeller 99065 99065
6 Gasket 99088 99088
7 Volute/Base 99098 99098
8 Intake Screen 99059 99059
9 Float Switch 92050 92055
10 Tethered Float Switch Clamp 99180 n/a
11 Vertical Float Switch Bracket n/a 99185
12 U-Bolt & Saddle Clamp Assembly 99462 99462
13 Battery Box (Complete Unit) 99464 99464
14 Cable Ties Purchase locally
15 Control Panel 99465 99465
16 AC Power Cord 99467 99467
17 Battery Terminals (+ & - ) 99460 99460
18 Check Valve 99505 99505
PARTS LIST
To order replacement parts, call 1-800-495-9278
15
13
18
16
9
9
12
