Operation
900004-00, 03/2017
Innovative Hearth Products
DRT2000 and DRC2000 Direct-Vent Fireplaces
71
REPLACEMENT PARTS (continued)
WARNING
Never use substitute materials. Use of non-approved parts can result in poor performance and safety hazards.
BURNER ORIFICES
33” Models 35” Models 40” Models 45” Models
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
--- Brass Orifi ce, Female—Natural Gas H8303 (#51) 1 21L82 (#49) 1 J7910 (#48) 1 60J80 (#44) 1
--- Brass Orifi ce, Female—Liquid Propane 35M91 (#61) 1 H3020 (#58) 1 62L37 (#56) 1 19L52 (#55) 1
WARNING
Failure to position the parts in accordance with these diagrams or failure to use only parts specifi cally
approved with this appliance may result in property damage or personal injury.
Table 56 - Homeowner Replacement Parts
Description
33” Models 35” Models 40” Models 45” Models
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
6 Hood F1900 1 F1837 1 F1838 1 F1901 1
7 Barrier F1902 1 F1839 1 F1840 1 F1903 1
1 Glass Door F1905 1 F1841 1 F1842 1 F1906 1
8 Control Compartment Door F1898 1 F1835 1 F1836 1 F1899 1
--- Touch-Up Paint (exterior) F1882 1 F1882 1 F1882 1 F1882 1
--- Touch-Up Paint (interior) F1881 1 F1881 1 F1881 1 F1881 1
--- Glowing Embers 88L53 1 88L53 1 88L53 1 88L53 1
--- Volcanic Stone 80L42 1 80L42 1 80L42 1 80L42 1
AVERTISSEMENT
Risque de dommages ou de blessures si les pièces ne sont pas installées conformément à ces schémas et
ou si des pièces autres que celles spécifi quement approuvées avec cet appareil sont utilisées.
