English
19
6
.3 Startup and normal operation
Before proceeding with the ignition remember:
ensure that the furnace door is well closed;
• that the fuel tank is full or at least contains enough fuel to run for the desired period.
W
hen the stove is connected to the power supply, but is not yet lit, the display will show the current time on its top half (example 1
2:30
)
and the word OFF on its lower half.
STARTUP
Action Description Display
Starts a cycle of three phases which take the
stove into normal operation:
On the lower part three circles will appear in succession
indicating the current phase of ignition.
• Phase one: CHECK UP (first 10 seconds)
-
The extractor fan activates for a few sec
-
onds.
O
K
S
ET
GRUPPO PIAZZETTA
1
2
3
4
5
6
A
L. F
SET
FLASHING SCRIPT
PHASE ONE
AL. C
• Phase two: IGNITION
- The fuel-loading chute is activated and
starts to feed pellets into the burner (the
LED on the display lights up at fixed time
intervals).
- The pilot light ignites (the LED on the dis-
play lights up).
- The extractor fan starts up.
OK
S
ET
GRUPPO PIAZZETTA
1
2
3
4
5
6
A
L. F
SET
FLASHING SCRIPT
PHASE TWO
AL. C
LED ON
• Phase three: STARTUP
-
If the pilot light has trigger
ed the combus
-
tion pr
ocess, the fuel-loading chute will
slow down to allow a period of stabilisation
and ther
efore a complete combustion of the
pellets in the subsequent operation.
- If during the startup phase the sensor on
the exhaust outlet shows an increase in
temperatur
e (sign that the combustion
process is under
way), the stove is consid
-
ered to be lit and operating normally.
-
If during the startup phase the sensor at the
exhaust outlet does NOT show an incr
ease
in temperature (sign that the combustion
process is not underway), the stove should
be consider
ed of
f; a new ignition cycle will
begin automatically and the three preceding
phases will be repeated in succession.
OK
SET
GRUPPO PIAZZETTA
1
2
3
4
5
6
AL. F
SET
FLASHING SCRIPT
PHASE THREE
AL. C
Hold the on/off key
down for several
seconds:
DT2040002-00
