SuperMax 19-38 - Page 26

26
19-38 DRUM SANDER OWNER’S MANUAL Technical Specifications
Index Part
No No Description Size Qty
31 ......... 480DS-131 ................... Dust Cover ................................................................................................ 1
32 ........ 480BS-132 ................... Handle ....................................................................................................... 1
33 ........ 480BS-133 ................... Pan Head Machine Screw ............................#8x1/2” ......................... 2
34 ........ 480DS-134 .................. Lock Washer ....................................................M3 .................................. 2
35 ........ 480BS-135 ................... Dust Cover Latch ..................................................................................... 1
36 ........ 480DS-136 .................. Phillips Flat Head Screw ...............................M3x0.5x10 .................... 2
37 ......... 480DS-137 ................... Sanding Drum ................................................. 1
38 ........ 480DS-138 .................. Nylon Insert Lock Nut ...................................M3x0.5 .......................... 2
39 ........ 480DS-139 .................. Inboard Abrasive Fastener .................................................................... 1
40 ........ 480DS-140 .................. Outboard Abrasive Fastener ................................................................ 1
41 ......... 480DS-141 ................... Carriage Bolt ...................................................5/16”-18x1” ................... 4
42 ........ 480DS-142 .................. Bearing .............................................................6205ZZ .......................... 2
43 ........ 480DS-143 .................. C-Ring ...............................................................S25 ................................. 2
44 ........ 480DS-144 .................. Drum Carriage ......................................................................................... 1
45 ........ 480BS-145 ................... Flat Washer .....................................................1/4” ................................. 5
46 ........ 480BS-146 .................. Round Socket Head Cap Screw ...................1/4”-20x1” ..................... 4
47 ........ 480BS-147 ................... Flat Washer .....................................................5/16” .............................. 4
48 ........ 480DS-148 .................. Bearing Seat ............................................................................................. 2
49 ........ 480BS-149 .................. Hex Cap Screw w/ Washer ...........................#10-24x3/8” ................. 2
50 ........ 480BS-150 .................. Dust Cover Catch .................................................................................... 1
51 ......... 480BS-151 ................... Stud ........................................................................................................... 1
52 ........ 480BS-152 ................... Spring ........................................................................................................ 1
53 ........ 480BS-153 ................... Tension Roller .......................................................................................... 2
54 ........ 480BS-154 ................... Bushing, Oilite ......................................................................................... 4
55 ........ 480BS-155 ................... Tension Roller Bracket, Inner Left ....................................................... 1
56 ........ 480BS-156 ................... Screw ................................................................#8-32x1” ........................ 4
57 ......... 480BS-157 ................... Spring, Tension Roller ............................................................................. 4
58 ........ 480BS-158 .................. Tension Roller Bracket, Inner Right ..................................................... 1
59 ........ 480BS-159 ................... Pad, Bracket-Tension Roller .................................................................. 2
60 ........ 480BS-160 .................. Bracket ...................................................................................................... 2
61 ......... 480BS-161 ................... Plate ........................................................................................................... 1
Parts List—Head Assembly (continued)
