SuperMax 19-38 - Default Chapter; Table of Contents

3
MANUAL
CONTENTS
SAFETY WARNINGS 4
ABOUT THE SUPERMAX
19-38 DRUM SANDER 5
Specifications: .....................5
QUICK SET UP GUIDE TO UNPACKING 6
SETTING UP THE 19-38 DRUM SANDER  11
Checking Drum Alignment ...........11
Dust Collection .....................12
Power And Electrical Safety ..........12
ABRASIVES  13
Abrasive Selection Guide ............13
Installing and Wrapping Abrasives ....13
Abrasive Wrap Tension Adjustment .. 14
Maximizing Abrasive Longevity ..... 14
OPERATING THE 19-38 DRUM SANDER 15
Basic Operating Procedures Checklist .15
Conveyor Belt Tension ...............17
Conveyor Belt Tracking ..............17
Tension Roller Pressure .............17
TROUBLESHOOTING  19
MAINTENANCE 22
Monthly Maintenance Checklist .....22
Cleaning the Machine ..............22
Replacing Conveyor Belts ..........22
TECHNICAL SPECIFICATIONS 23
Wiring Diagram ...................23
Head Assembly .................... 24
Parts List—Head Assembly ..........25
Conveyor and Motor Diagram .......28
Parts List—Conveyor and Motor .....29
SUPPLY CHECKLIST AND
ORDER INFORMATION  31
NOTES 32
