SuperMax 19-38 - Page 30

30
19-38 DRUM SANDER OWNER’S MANUAL Technical Specifications
Index Part
No No Description Size Qty
32 ........ 480BS-232 .................. Washer, Lock-Int. Tooth ................................1/4” ................................. 2
33 ........ 480BS-233 .................. Screw, Round Head- Slotted .......................1/4”-20x1-3/4” .............. 2
34 ........ 480BS-234 .................. Bracket, Take Up-Base ........................................................................... 2
35 ........ 480BS-167 ................... Lock Washer ....................................................5/16” .............................. 4
36 ........ 480BS-236 .................. Roller, Drive .............................................................................................. 1
37 ......... 480BS-237 ................... Bracket, Support-Drive Roller .............................................................. 1
38 ........ 480BS-238 .................. Bed, Conveyor ......................................................................................... 1
39 ........ 480BS-239 .................. Socket Head Cap Screw ................................5/16”-18x3/4” ............... 2
40 ........ 480DS-240 ................. Belt Conveyor, Abrasive (Not Shown) ................................................ 1
41 ......... 480BS-204 .................. Flat Washer .....................................................5/16” .............................. 1
42 ........ 480BS-242 .................. Hex Nut ............................................................5/16“-24 ........................ 1
43 ........ 480BS-243 .................. Slotted Set Screw ...........................................#8-36x5/16” ................. 1
44 ........ 480BS-244 .................. Strain Relief, Gear Motor .............................6N-4 .............................. 1
45 ........ 480BS-245 .................. Hex Nut ............................................................5/16”-18 ......................... 2
Parts List—Conveyor and Motor (continued)
