15
Chapter 1: Introduction
Note: The table above is continued on the next page.
Motherboard Features
CPU
• Intel® Atom SoC C3000 series (FCBGA1310) processor
Memory
• Up to 256GB RDIMM or 64GB UDIMM DDR4 ECC/Non ECC with speeds of up to 2400MHz
DIMM Size
• Up to 32GB at 1.2V
Expansion Slots
• One (1) PCI Express 3.0 x4 Slot
• One (1) M.2 PCI Express 3.0 x2 / I-SATA Slot
Network
• Intel X557-AT2 Base-T PHY
• CS4227 SFP+ PHY (TP4F only)
BaseBoard Management Controller (BMC)
• ASpeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0
• One (1) Dedicated IPMI LAN port located on the rear IO back panel
Graphics
• Graphics controller via ASpeed 2400 BMC
I/O Devices
• Serial (COM) Port
• SATA 3.0 Ports
• One (1) serial port header
• Twelve (12) SATA 3.0 ports (four ports, eight ports via miniSAS)
Peripheral Devices
• Two (2) USB 2.0 ports on the rear I/O panel (USB0/1)
• One (1) internal USB 2.0 header with two (2) USB connections each for front access (USB2/3)
• One (1) USB 3.0 Type A Port (USB4)
BIOS
• 128 Mb SPI AMI BIOS
®
SM Flash UEFI BIOS
• ACPI 4.0, USB keyboard, Plug-and-Play (PnP), SPI quad speed support, Riser card auto detection support, RTC (Real
Time Clock) wakeup, Dual Boot Block support, and SMBIOS 2.7
Motherboard Features
