2-2
Add-on Card User's Guide
2-2 Front Connector and LED Defi nitions
1. LAN Ports
LAN ports allow the Add-on card to connect
a maximum of two network cables (CX4 con-
nectors). Each LAN port provides up to 10
gigabits per second connection speed and
require CX4 copper-based cables for maxi-
mum throughput.
The ports are designated Port 1 and Port 2.
2. LAN Port LEDs
Each LAN port includes four LEDs. The LEDs
indicate connection, activity, and connection
speed (in Giga-bits/second). Review the table
to the right for LEDs defi nitions.
Port 1 LEDs
LED Color Defi nition
Number
1 Yellow Link speed 1 Gb/
second
2 Green Link speed at 10
Gb/second
3 Yellow Optical cable con-
nected
4 Green LAN activity
Port 2 LEDs
LED Color Defi nition
Number
5 Yellow Link speed 1 Gb/
second
6 Green Link speed at 10
Gb/second
7 Yellow Optical cable con-
nected
8 Green LAN activity
To Next Page
