Chapter 2: Installation
Memory Support and Installation
Note: Check the Supermicro website for recommended memory modules.
Important: Exercise extreme care when installing or removing DIMM modules to prevent
any possible damage.
Memory Support
The H11DSi-NT supports Up to 2 TB of ECC DDR4 2667 MHz speed, RDIMM/LRDIMM/3DS/
NVDIMM memory in sixteen (16) slots. Refer to the table below for additional memory
information.
Processors and their Corresponding Memory
Modules
CPU#
Channel Channel Channel Channel
1 2 3 4 5 6 7 8
4 DIMMS
CPU1
B1 D1 F1 H1
8 DIMMS
CPU1
A1 B1 C1 D1 E1 F1 G1 H1
8 DIMMS
CPU1
B1 D1 F1 H1
CPU2
B1 D1 F1 H1
16 DIMMS
CPU1
A1 B1 C1 D1 E1 F1 G1 H1
CPU2
A1 B1 C1 D1 E1 F1 G1 H1
Populating RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS DDR4 Memory
Modules
Type
DIMM
Population
Maximum DIMM
Capacity (GB)
Maximum Frequency
(MHz)
1 Channel 4 Channel
RDIMM
1R 16GB 64GB 2666
2R 32GB 128GB 2400
LRDIMM
4R 64GB 256GB 2666
8R 128GB 512GB 2666
LRDIMM 3DS
2R2H 64GB 256GB 2400
2R4H 128GB 512GB 2400
