Chapter 2: Installation
LAN Enable/Disable
Jumper JPL1 will enable or disable the LAN ports on the motherboard. See the table below
for jumper settings. The default setting is enabled.
GLAN Enable
Jumper Settings
Pin# Denition
1-2 Enabled (default)
2-3 Disabled
