SuperServer E300-9D-4CN8TP/E300-9D-8CN8TP User's Manual
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open: Normal, Closed: Clear CMOS
JI2C1, JI2C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled)
JNS1 Mini-SAS HDD NVMe/SATA Mode Select Pins 1-2: SATA (Default), Pins 2-3: NVMe
JPG1 Onboard VGA Enable Pins 1-2 (Enabled)
JPL1 LAN1/2/3/4 Enable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Select Pins 1-2 (Normal)
JPUSB1 USB Wake Up Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)
LED Description Status
LED1 Power LED Solid Green: Power On
LED2 UID LED
LED3 Overheat/PWR Fail/Fan Fail
Solid Red: Overheat
Blinking Red: PWR Fail or Fan Fail
LEDM1 BMC Heartbeat Blinking Green: BMC Normal
Connector Description
BT1 Onboard Battery
COM1 COM Header
FAN1 - FAN4, FANA, FANB System/CPU Fan Headers
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0-3, I-SATA4-7
Eight Intel® PCH SATA 3.0 Ports or Two NVMe U.2 Ports
JD1 PWR LED/Buzzer Header (Pins 1-4: PWR LED, Pins 5-7: Buzzer)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JIPMB1 System Management Bus Header (for IPMI only)
JL1 Chassis Intrusion Header
JLANLED1 LAN1 - LAN4 Activity LED Header
JMD1 M.2 PCI-E 3.0 x4/S-SATA5 Connector (M-Key 2280)
JMD2 M.2 PCI-E 3.0 x2/S-SATA4 Connector (B-Key 3042)
JMD1_SRW1, JMD2_SRW1 M.2 Holding Screws
JMP1 Mini PCI-E x1 Connector
JMP1_SRW1 Mini PCI-E x1 Connector Holding Screw
JNVI2C1 NVMe I
2
C Header
JPI2C1 Power I
2
C System Management Bus (Power SMB) Header
JPH1 4-pin Power Connector for HDD use
