Chapter 2 Maintenance and Component Installation
2.3 Motherboard Components
Processor
The E300-9D-4CN8TP/E300-9D-8CN8TP system features an embedded
Intel® Xeon® D-2123IT, 4-core/D-2146NT, 8-core processor.
Memory Support
The X11SDV-4C-TP8F/8C-TP8F motherboard supports up to 512GB of DDR4-2666/2400/2133
ECC LRDIMM or up to 256GB of DDR4-2666/2400/2133 ECC RDIMM memory in four DIMM
slots. Populating these DIMM slots with memory modules of the same type and size will result
in interleaved memory, which will improve memory performance.
Note: Check the Supermicro website for recommended memory modules.
Memory Population (Balanced)
DIMMA1 DIMMB1 DIMMD1 DIMME1
Total System
Memory
4GB 4GB 8GB
4GB 4GB 4GB 4GB 16GB
8GB 8GB 16GB
8GB 8GB 8GB 8GB 32GB
16GB 16GB 32GB
16GB 16GB 16GB 16GB 64GB
32GB 32GB 64GB
32GB 32GB 32GB 32GB 128GB
64GB 64GB 128GB
64GB 64GB 64GB 64GB 256GB
128GB 128GB 256GB
128GB 128GB 128GB 128GB 512GB
