Supero X10DRi User Manual

Chapter 1: Overview
1-5
X10DRi/X10DRi-T Jumpers
Jumper
Description Default Setting
JBT1
Clear CMOS See Chapter 3
JI
2
C1/JI
2
C2
SMB to PCI-E Slots Pins 2-3 (Disabled)
JPB1 BMC Enable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 GLAN1/GLAN2 Enable (X10DRi)
(10G) TLAN1/TLAN2 Enable (X10DRi-T)
Pins 1-2 (Enabled)
JPME2 Manufacture (ME) Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
X10DRi/X10DRi-T Connectors
Connectors Description
Battery Onboard CMOS Battery (See Chpt. 3 for Used Battery Dis-
posal)
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
Fan1-6, FanA-B CPU/System Fan Headers
J24 24-pin ATX Main Power Connector (See Warning on Pg. 1-6.)
JD1 Speaker/Power LED
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JOH1 Overheat LED Indicator
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPWR1/2 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)
JSD1/JSD2 SATA DOM (Device on Module) Power Connectors
JSTBY1 Standby Power Connector
JTPM1 TPM (Trusted Platform Module)/Port 80 Header
JUIDB1 UID (Unit Identication) Button
LAN1/LAN2 G-bit Ethernet (GLAN) Ports 1/2 (X10DRi)
10G-bit Ethernet (TLAN) Ports 1/2 (X10DRi-T)
(IPMI) LAN IPMI_Dedicated LAN support by the Aspeed controller
(I-)SATA 0-5 SATA 3.0 Connectors supported by Intel PCH (I-SATA 0-5),
(I-SATA4/I-SATA5: used w/Supermicro SuperDOMs (Devices-
on-Module with built-in power pins)
(S-)SATA 0-3 SATA 3.0 Connectors supported by Intel PCH (S-SATA 0-3)
(CPU1) Slot1 PCI-Express 3.0 x8 Slot from CPU1
(CPU1) Slot2 PCI-Express 3.0 x16 Slot from CPU1
(CPU1) Slot3 PCI-Express 3.0 x8 Slot from CPU1
