1-8
X10SLM-F/X10SLL-F/X10SLL-SF/X10SLL-S User’s Manual
X10SLM-F_X10SLL-(F/SF/S) Jumpers
Jumper Description Default
JI
2
C1/JI
2
C2 SMB to PCI Slots Off (Disabled)
JPB1 (-F Models only) BMC Enable Pins 1-2 (Enabled)
JBR1 BIOS Recovery Pins 1-2 (Normal)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1/JPL2 LAN1/LAN2 Enable Pins 1-2 (Enabled)
JPME1 ME Recovery Pins 1-2 (Normal)
JPME2 Manufacturing Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Enable Pins 1-2 (Reset)
X10SLM-F_X10SLL-(F/SF/S) Headers/Connectors
Connector Description
BT1 Onboard Battery
COM1/COM2 COM1/COM2 Port Headers
Fan1-Fan4, FanA System/CPU Fan Headers
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JL1 Chassis Intrusion Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JPI
2
C1 Power System Management Bus (Power SMB)
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 4-pin CPU power Connector (Required)
JSD1 SATA DOM (Device_On_Module) Power Connector
JSTBY1 Wake-On-LAN Enable Header
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)
(IPMI_)LAN (for -F Models) IPMI_Dedicated Gigabit (RJ45) Port
SP1 Internal Speaker/Buzzer
I-SATA0-I-SATA5 (Intel PCH) Serial ATA (SATA 3.0/2.0) Ports 0-5 (Ref. Model Table on
P. 1-4)
(CPU) Slot 6 PCI-Express 3.0 x8 in x16 Slot
(CPU) Slot 5 PCI-Express 3.0 x8 Slot
(PCH) Slot 4 PCI-Express 2.0 x4 in x8 Slot (X10SLM-F/x10SLL-F Only),
T-SGPIO 1/2 Serial_Link General Purpose I/O Connection Headers 1/2
USB 3.0-0 (USB0) Front Accessible Vertical USB 3.0 Type A Header
USB 3.0-2/3 (USB2/3) Front Accessible USB 3.0 Header 2/3 (for X10SLM-F Only)
