1-6
X9DAi Motherboard User's Manual
Warning: To prevent damage to the power supply or motherboard, please use a power
supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect
these power supply connectors to the 24-pin power connector (J22) and two 8-pin
power connectors (JPWR1, JPWR2) on the motherboard. Failure in doing so will void
the manufacturer warranty on your power supply and motherboard.
LAN1/2 G-bit Ethernet Ports 1/2
SP1 Onboard Buzzer (Internal Speaker)
STBY1 Standby Power Header
T-SGPIO 1/2 Serial-Link General_Purpose IO Headers 1/2
USB 2.0 0/1/2/3 Back Panel USB 2.0 Ports 0/1/2/3
USB 2.0 4, 5/6 Front Panel Accessible USB 2.0 Connections 4, 5/6
USB 3.0 0/1 Back Panel USB 3.0 Ports 0/1
USB 3.0 2/3 Front Panel Accessible USB 3.0 Connections 2/3
X9DAi LED Indicators
LED Description State Status
LE1 Standby PWR LED Green: On SB Power On
