Supero X9DAi User Manual

Chapter 1: Overview
1-5
JPME1 ME Recovery Pins 2-3 (Normal)
X9DAi Jumpers
Jumper
Description Default Setting
J29/J30
SMB Enable Pins 1-2 (Enabled)
JBT1
Clear CMOS See Chapter 2
JI
I2
C1/JI
I2
C2 SMBus to PCI-E Slots Pins 2-3 (Normal)
JPI1 IEEE1394a Enable Pins 1-2 (Enabled)
JPL1/2 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPME1 Management Engine (ME)
Recovery Mode
Pins 1-2 (Normal)
JWD1 Watch Dog Pins 1-2 (Reset)
X9DAi Connectors
Connectors Description
7.1 Audio 8 Channel (7.1) High-Denition Backplane Audio Connector
BT1 Onboard CMOS Battery (See Chapter 3 for Used Battery Disposal)
CNF1/CNF2 IEEE 1394a 1/2 Connectors
COM1 Backplane COM Port1
CPU1 Slot1/Slot3 PCI-E 3.0 x16 Slots (The slots are available when CPU1 is installed.)
CPU2 Slot5 PCI-E 3.0 x16 Slot (This slot is available when CPU2 is installed.)
CPU1 Slot2 PCI-E 3.0 x4 Slot (This slot is available when CPU1 is installed.)
CPU2 Slot4/Slot6 PCI-E 3.0 x8 Slots (The slots are available when CPU2 is installed.)
FAN1~7, FANA CPU/System Fan Headers (Fan6/Fan7: CPU 1/2 Fans)
I-SATA 0~5 Intel SB SATA Connectors 0~5 (SATA 0/1: SATA3 Ports, SATA2~5: SATA
2 ports)
J18 Audio Header
J22 ATX 24-Pin Power Connector (See Warning on Page 1-6.)
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JL1 Chassis Intrusion
JOH1 Overheat/Fan Fail LED Indicator
JPI
I2
C1 Power Supply SMBbus I
2
C Header
JPWR1/JPWR2 12V 8-Pin Power Connectors (See Warning on Page 1-6.)
JSD1 SATA DOM (Device_On_Module) Power Connector
JSPDIF_In SPDIF_(Sony/Philips Digital Interface)_In Header
JSPDIF_Out SPDIF_(Sony/Philips Digital Interface)_Out Header
JTPM1 TPM (Trusted Platform Module)/Port 80 Header
(PS2) KB/Mouse Keyboard/Mouse

Supero X9DAi Specifications

General

Brand	Supero
Model	X9DAi
Category	Motherboard
Language	English
