Superwinch S5000 - Page 3

Description Quantity
Winch assembly with wire rope including lead wires 1
Circuit breaker assembly with hardware 1
Handsaver 1
Mounting hardware kit 1
Remote pendant 1
Owner’s manual 1
This carton contains the following items. Please unpack carefully.
Read instructions before beginning.
UNPACKING
DIMENSIONS
S3000, S4000, S5000
Figure 2
PERFORMANCE
Wire Rope Max. Pulling Capacity
Layer lbs. kg
1 3,000 1364
2 2,250 1021
3 2,000 907
4 1,750 794
Motor
Load Speed Current
lbs. kg ft/min m/min Amps
0 0 17.0 5.1 15
1,000 454 12.5 3.8 70
2,000 907 9.0 2.7 117
2,500 1134 7.5 2.3 155
3,000 1361 4.5 1.4 220
S3000
Wire Rope Max. Pulling Capacity
Layer lbs. kg
1 4,000 1818
2 3,000 1361
3 2,600 1179
4 2,000 998
Motor
Load Speed Current
lbs. kg ft/min m/min Amps
0 0 21.6 6.5 30
1,000 454 16.0 4.8 90
2,000 907 12.4 3.8 155
2,500 1134 10.6 3.2 180
3,000 1361 8.8 2.7 215
3,500 1589 6.2 1.9 250
4,000 1814 4.5 1.4 311
Wire Rope Max. Pulling Capacity
Layer lbs. kg
1 5,000 2273
2 4,000 1814
3 3,500 1588
4 2,900 1315
Motor
Load Speed Current
lbs. kg ft/min m/min Amps
0 0 17.5 5.9 36
1,000 454 14.5 4.6 80
2,000 907 12.0 3.4 135
3,000 1361 9.5 2.2 200
4,000 1814 7.3 1.3 265
5,000 2268 4.5 1.4 350
S4000
S5000
* Based on first layer performance
NOTES
1. All dimensions are in inches [millimeters].
2. Typical mount is to flat surface capable of handling the loads. Bolts to be Grade 5 or better.
6.0
(152)
15.1
(383)
7.2
(183)
7.1
(180)
3.1
(79)
5.9
(150)
3.69
(93.7)
1.24
(31.5)
ROLLER FAIRLEAD
SCREWS
DRUM SUPPORT
PLATE SCREWS
MOTOR
SCREWS
4 5
DRUM SUPPORT
PLATE
