18
Installation
Wiegand IN
D1
D0
GND
Wiegand Device
Door sensor and Exit button
SUPERVISED INPUT terminals No. 0 ~ No. 7 can be set to be used for normal TTL input or supervised input.
IN-
IN+
Door
sensor
Door
Exit button
IN-
IN+
