SUPREME 1700TR - Page 46

Mechanical Stationary
Operator’s Manual
© 05/2020 300-0804
43
APPENDICES
Dinamica Generale
Sensor Cable
1 2 3
Cap/Plug
Sensor Cable
1 3 42
Sensor Cable
1 2 3 4
5 6
Cap/Plug
Figure 32
Weighbar Points
3 Point Weighing System
4 Point Weighing System
6 Point Weighing System
Sensor Cable
1 2 3
Cap/Plug
Sensor Cable
1 3 42
Sensor Cable
1 2 3 4
5 6
Cap/Plug
Sensor Cable
1 2 3
Cap/Plug
Sensor Cable
1 3 42
Sensor Cable
1 2 3 4
5 6
Cap/Plug
FRAME: ASSY, 300STM/400STM
FRX511
1
2
3
FRAME: ASSY, MECH, 6TS/7TS
FRX865
1
2
3
4
FRAME: KIT, MECH,
DETACHABLE, 15TRS/17TRS
100-4073
1
2
3
4
5
6
