6
To facilitate the installation, you may want to remove
the salt lid and main cover from the appliance.
- In case of high concentration of impurities in the inlet
water, we recommend the installation of a sediment filter,
ahead of the appliance.
- We strongly recommend the use of flexible hoses
to connect the appliance to the water distribution system;
use hoses with a large diameter in order to limit
the pressure loss.
- If the appliance is not equipped with the factory bypass
(optional), we strongly recommend to install a 3-valve
bypass system (not included with this product!) to isolate
the appliance from the water distribution system in case
of repairs. It allows to turn off the water to the appliance,
while maintaining (untreated) water supply to the user.
1. mains water supply (untreated water).
2. inlet of appliance (untreated water).
3. outlet of appliance (treated water).
4. house/application (treated water).
STEP 1. Screw the factory bypass onto the elbow
connections of the appliance (2 & 3); make sure to install
the gasket seals. Tighten the nuts firmly by hand.
STEP 2. Screw the connection kit with nuts onto the factory
bypass (1 & 4); make sure to install the gasket seals.
Tighten the nuts firmly by hand.
STEP 3. Connect the mains water supply to the adaptor
on the inlet port of the factory bypass (1).
STEP 4. Connect the house/application to the adaptor
on the outlet port of the factory bypass (4).
WITH FACTORY BYPASS (optional).
2
3
4
1
INSTALLATION
INLET & OUTLET
