Audio Output
6, Mixed Line output – J25
Besides speaker output, JAB2 provides a mixed line output.
After frequency setting in the PC UI, you can use it as subwoofer
signal and build an audio 2.1 system.
Please note that it’s line output signal, so an amplifier board is
required for connecting with a speaker.
J25
6
