Control
9, Shutdown Control – J5
Shutdown control function is equipped on JAB2.
Short circuit J5 to enter into shutdown mode, in which
mode, JAB2 would be powered off.
Once you release the short circuit, JAB2 will re-run.
You can find the PH-2Pos shutdown control cable in
the Functional cable kit (AA-JA11114 / AA-JA11116).
9
J5
