Power adapter & Battery board
Power Supply
2
2, Battery board – J1
JAB2 supports battery power which improves the
portability.
MPPT charging circuit is equipped in JAB2. So, you can
use AA-JA11113 to power JAB2.
When you want to charge batteries with AA-JA11113,
connect the power supply and battery board together
with JAB2. The voltage of the power supply is suggested
to be larger than 15V and the current is larger than 1A.
J1
