Any customizable requirements on interfaces, materials and length of cables, please
A-1 JST PHR-5-BK
A-2 AWG24 Black Cable
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
Unit：mm
1、AWG24, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
2、PIN5 is idle.
A-1 JST PHR-5-BK Multi-view
OverviewAUX Line-in Cable
500.000
A-1 A-2 A-3
A-3 HONGBO PJ-341*M-4P
A-1
JST PHR-4-BK
A-2 AWG24 Red & Black Cable
PIN 4
PIN 3
PIN 2
PIN 1
Unit：mm
1、AWG24, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
A-1 JST PHR-4-BK Multi-view
500.000
A-1 A-2
Tinned(Unleaded)
Tinned(Unleaded)
Tinned(Unleaded)
Battery Charging Cable Overview
A-2
AWG22 Red & Black Cable
Unit：mm
1、AWG22, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
A-1
Overview
Tinned(Unleaded)
Power Cable
MOLEX 43645-0200 Multi-view
A-1 A-2
Tinned(Unleaded)
PIN 2
PIN 1
PIN 3
PIN 4
A-1 MOLEX 43025-0400
A-2
A-1 A-2
A-1
Speaker Cable
AWG22 Red & Black Cable
Multi-view
1、AWG22, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
Tinned(Unleaded)
Tinned(Unleaded)
Unit：mm
Overview
A-1 JST PHR-6-BK
A-2 AWG24 Black Cable
Unit：mm
1、AWG24, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
A-1 JST PHR-6-BK Multi-view
OverviewVolume Control Cable
PIN 6
PIN 5
PIN 4
PIN 3
PIN 2
PIN 1
500.000
A-1 A-1A-2
A-1 JST PHR-2-BK
A-2 AWG24 Black Cable
Unit：mm
1、AWG24, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
A-1 JST PHR-2-BK Multi-view
OverviewSwitch Cable
PIN 2
PIN 1
Tinned(Unleaded)
500.000
A-1 A-2
Tinned(Unleaded)
Tinned(Unleaded)
A-1 JST PHR-2-BK
A-2 AWG24 Black Cable
Unit：mm
1、AWG24, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
A-1 JST PHR-2-BK Multi-view
OverviewLED Indicator Cable
PIN 2
PIN 1
500.000
A-1 A-2 A-3
A-3 LED Lamp-socket
Interface extension cable is attached with interface board package.
Battery charging cable is attached with battery charging board package.
Basic Cables Package (Default package with JAB): Power Cable x 1, Speaker Cable x 1,
Bluetooth Antenna x 1
JAB1/2 Functional Cables Package (Optional): Battery Charging Cable x 1, Switch Cable x 1, Aux Line-in Cable x 1, Volume Control Cable x 1,
Bluetooth Control Cable x 1, LED Indicator Cables: Red x 1, Blue x 1, Green x 1
LED Light Color: Red, Blue, Green
2
JST PHR-4-BK terminals
on both sides
A-1 JST PHR-2-BK
A-2 AWG24 Black Cable
Unit：mm
1、AWG24, Temperature resistance: 80 ,
Voltage rating: 300V, Length: 500mm.
A-1 JST PHR-2-BK Multi-view
OverviewBluetooth Control Cable
PIN 2
PIN 1
500.000
A-1 A-2 A-3
A-3 Push Button Switch
