Sussman ES - Boiler Specifications; Steam Pressure Temperature Chart

Sussman Boilers
Installation, Operation & Maintenance Manual
Specifications
Steam Gauge
Pressure/
Temperature
Chart
18
__________________________________________
Boiler Bhp Lbs/Hr 3-Ph
Model No. KW Rating Steam** Volts*** Amps
__________________________________________
208 34
ES-12* 12 1.22 36.2 240 29
480 15
__________________________________________
208 50
ES-18* 18 1.84 54.2 240 44
480 22
__________________________________________
208 67
ES-24* 24 2.45 72.3 240 58
480 29
__________________________________________
208 84
ES-30 30 3.06 90.4 240 73
480 37
__________________________________________
208 100
ES-36 36 3.67 108 240 87
480 44
__________________________________________
208 134
ES-48 48 4.90 145 240 116
480 58
__________________________________________
208 167
ES-60 60 6.12 181 240 145
480 73
__________________________________________
208 200
ES-72 72 7.35 217 240 174
480 87
__________________________________________
208 300
ES-100 108 11.2 325 240 260
480 130
__________________________________________
208 400
ES-135 144 14.7 434 240 347
480 173
__________________________________________
ES-160 158 16.2 475
240 379
480 190
__________________________________________
ES-180 180 18.4 542
240 434
480 217
__________________________________________
* Single phase available
** @ 212˚ F
*** Other voltage available
________________
Gauge Temperature
Pressure
PSIG
F˚ C˚
________________
15 179 82
________________________
10 192 89
________________________
5 203 95
________________________
0 212 100
________________________
1 215 102
________________________
3 221 105
________________________
5 227 111
________________________
9 237 114
________________________
11 241 119
________________________
15 250 121
________________________
17 253 123
________________________
19 257 125
________________________
21 260 127
________________________
23 264 129
________________________
25 267 131
________________________
27 270 132
________________________
29 273 134
________________________
31 275 135
________________________
33 278 137
________________________
35 281 138
________________________
37 283 139
________________________
39 286 141
________________________
41 288 142
________________________
43 290 143
________________________
45 292 144
________________________
47 295 146
________________________
49 297 147
________________________
51 299 148
________________________
53 300 149
________________________
55 303 151
________________________
60 308 153
________________________
65 312 156
________________________
70 316 158
________________________
75 320 160
________________________
80 324 162
________________________
85 327 164
________________________
90 331 166
________________________
95 335 168
________________________
100 338 170
________________________
